DW 028XLHR 3D Printer
DW 028XLHR is a reliable, high-speed, high-precision 3D printing system for rapid manufacturing, specifically developed to allow small to medium sized jewellery workshops to produce very high-quality models, with no limits on shape or geometric complexity.
The DW 028XLHR 3D printer can produce richly detailed models with smooth and ornate surfaces, undercuts and cavities, ensuring the greatest possible freedom when designing pieces.
The combination between DW 028XLHR 3D printer and DWS high-performance materials, can produce richly detailed models with smooth and ornate surfaces, undercuts and cavities, ensuring the greatest possible freedom when designing pieces. It is also perfect for creating fashion accessories and models for fashion jewelry.
With low running costs and zero planned maintenance costs, this printer has been designed for long-term uninterrupted operation.
It is compatible with the full range of materials DWS has developed specifically for jewellery applications.
The DW 028XLHR 3D printer offers a printing area of 100x100x100 mm and can produce up to 150 models per day, detailed with smooth surfaces, undercuts, cavities and watermarks, ensuring maximum freedom in model design.
Main Features of DW 028XLHR 3D Printer :
- Fast and highly precise printer for rapid prototyping
- Very low operating and maintenance costs
- Production of for filigree, extra-thin models, and extremely fine detail
Technical Specification of DW 028XLHR 3D Printer :
Technology | Laser Stereolithography |
---|---|
Working Area | 100 x 100 x 100 mm (depending on the version) |
Laser Source | Solid State BluEdge® |
Slice Thickness | 10-100 microns (the actual value depends on the material used) |
Scanning Method | Galvanometer |
Software | Nauta® Plus and Fictor® |
Input File Format | stl, .slc, .nauta, .fictor, .mkr, .3dm, 3ds, .ply, .obj, .lwo, .x |
Machine Size | 380 x 515 x 733 mm |
Weight | 56 Kg |
Operating Temperature and Humidity | 20°-25°C / 60% |
Power Supply | AC 230/115 V / 50-60 Hz |
Electrical Consumption | 400W |
PC Minimum Requirements | External PC included |
I/O Interfaces | 1 USB port - 1 TCP/IP ethernet port |
Connectivity | 1 Active internet connection |
